EB384 Nidec 5 HP 3600 RPM 230V 56 Frame (Base) ODP Air Compressor Motor

• 5 HP 3600 RPM (1 speed), 21.5 amps 230V Volts 60 Hz Capacitor Start/Run Motor
• 56 Frame, Rolled Steel, Keyed Shaft 7/8″ Diameter x 2 3/8″
• Service Factor = 1.0, Overload Protection: Manual
• Rigid Base Mount, Ball Bearings, Class F Insulation, CCW drive end
• 1 Year Manufacture Warranty

Motor for air compressor requiring a high break-down torque. Wiring diagram on motor name plate. ODP = Open Drip-Proof, T063CJW2054013B
