Original price was: $236.30.$99.99Current price is: $99.99.
- Multiple payment methods, 100% payment security
- Quality at its Finest
- Uncompromising quality, every time.
- Get Quality, Get More
- 1/16 hp 3450 RPM, .3 amps, 460 Volts Single Phase
- Permanent Split Capacitor
- Shaft: 5/16″ x 3 1/3″; Rotation = CCWSE
- Stud Mount – Bolt Circle – 2.85″
- Ball Bearings
- Motor Length Less Shaft = 4 3/4″
- 1 Year Manufacture Warranty
Application: Flue Exhaust Draft Booster Blower Motor. Includes 4 MFD Capacitor. Has Hall Effect Sensor. Reference Information: Carrier BDP HC30GB460, HC30GB462, JF1H091, JF1H101. York 024-24115-009. Replaces AO Smith/Century 9625. Dayton 48X971, 48GN75. Carrier Sensor Assembly (50HJ 401 484) not included.
Be the first to review “Fasco D1184 Motor | 1/16 Hp 3450 RPM CCW 3.3″ Diameter 460 Volts”
